SOLENOID ACTUATED(SHUT OFF VALVE) NORGREN  TYPE:85750

FAIL CLOSE, 110V/264MA, PA: 0 TO 40 BAR

CONNECTION:1 NPFT, CAT NO: 8499976.8901

TAG NO: XV41201D,E,F

859xxxx.8901.11000 = 86754xx.8901.11000, xx = 07 + 22 + 23,

Series ………….  86750

Designation ……..  2/2-Way solenoid valve

Type ……………  piston valve

Operation ……….  force lifted

Connection ………  NPT 1

Press.rating …….  PN 40

ND ……………..  25 mm

Pressure ………..  0 – 40 bar

kv-value ………..  10 m³/h

Temp.medium ……..  -40 up to +90°C

Temp.ambient …….  T5: -40 up to +40°C

                      T4: -40 up to +60°C

Voltage …………  110 V

Frequency ……….  00 Hz

Ex-prot. class …..  II 2G Ex de IIC T4/T5

                      II 2D Ex tD A21 IP65 T130°C/T95°

Ex-Certificate …..  PTB 10 ATEX 1021 X

Prot.class ………  IP 65

EAC Ex-prot. class .  1Ex de IIC T4, T5 Gb X

                      Ex tb IIIC T130°C,T95°C Db X

EAC Ex-Certificate .  RU C-GB.AA87.B.00708

EAC testing laborato  NANIO CCVE

Terminal ………..  junction box for cable diameter

                      6,5 – 11.5 mm

                      cable entry M20 x 1.5 mm

Cons.holding …….  264 mA

Duty cycle ………  100 %

Mounting ………..  optional, solenoid preferably

                      mounted vertical on top

Body material ……  stainless steel

Sealing material …  NBR-K

Switching function .  normally closed (NC)

Mech.equip. ……..  electrical position indicator with

                      2 limit switches

Sol switch ………  protection class: IP 67

                      visual indicator: LED

                      electr. connection: cable 2×0,14mm²

                      10m long, Temp. range:-40°C…+70°C

                      Control Command/Evaluating:

                      switching Amplifier (not our part

                      to supply);

                      Type: Namur DIN EN 60947-5-6

                      ATEX II 2G for Zone 1

Remark ………….  Product information attached to

                      shipment

Warranty ………..  This product contains wearing

                      parts. Fair wear and tear depends

                      on the application.

Testing current ….  185mA

Appr/Certificate(me)  Article 4 Paragraph 3 acc. to PED

Appr/Certificate(el)  CE 0044 acc. to ATEX category 2

Devices Conformity .  CE 0044
