Bently Nevada 3500/40M 125680-01 Proximitor I/O Module with Internal Terminations

An essential device that forms part of the 3500/40M condition monitoring system of Bently Nevada Company is the Bently Nevada 3500/40M 125680-01 Proximitor I/O Module with Internal Terminations. Basically, functions as an intermediary between different Proximitor sensors and the central 3500/40M system; thus, it makes possible to collect and analyze critical vibration data.

Main Concepts and Features:

• Proximitor I/O: The module gets its energy from the Proximator sensors painlessly and without conflict in the rotating machines. This module offers signal conditioning and termination points to these sensors.
• Internal Terminations: The “Internal Terminations” technique eliminates the need for external wiring and termination blocks, provides easy installation and lowers incorrect misconnections. This design also enhances the module’s reliability while the maintenance requirements get reduced.
• Data Acquisition: The module retrieves the vibration data from the connecting Proximitors and transfers it to the 3500/40M for the next analysis and processing phases.
• Signal Conditioning: Mandatory signal conditioning operations such as amplification, filtering, and impedance correction are performed for assuring accurate and reliable data transmission.
• Integration with 3500/40M: Effortless inclusion with the 3500/40M system is made possible by the module, thus, enabling data transfer and condition monitoring at the highest level.
