The FAM3200 is an armored purgemeter designed to meter small gas and liquid flows. This meter is especially suited for applications with cloudy, opaque or aggressive fluids in chemical and pharmaceutical industries, gas analyzers, process systems, well systems and wherever glass metering tubes cannot be used for safety reasons. The solution for the following application areas:

Water purification
Gas sampling systems, nitrogen generators
Burner control
Chemical injection
Food and beverage applications General specifications:

Application
– Clean, low viscosity liquids and gases
Mounting
– Vertically, in line or wall mouted
Connections
– 1/4 to 1 in., threaded, vertical or horizontal
Flow ranges
– Water flows: 1 to 3000 l/h
Flow turndown
– Typically 10:1
Operating pressure
– Up to 100 bar (1450 lbf/in 2 g)
Operating temperature
– Up to 180 °C (356 °F)
Accuracy
– Class 6
Alarms
– Slot sensors, up to 2 off
Tube material and float material
– Stainless steel
